Home » Producten » Advantech PPC-315S ADL Panel PC
Advantech

Advantech PPC-315S ADL Panel PC

Panel PC Intel® Quad Core N97 processor, 15 ” display
  • 15″ Display, 1024 x 768, PCAP-touch
  • Intel® Quad core N97
  • DDR5 RAM (max. 1 x 16GB)
  • 24 VDC voeding
  • 2 x LAN 10/100/1000 Mbps
  • 4  x USB, 2 x COM.DP
  • PCI & PCIe optie
  • Windows, Linux, Android

Offerte aanvraag
Dit product is al toegevoegd aan de offerte aanvraag
Ga naar mijn offerte aanvraag
  • Description
  • Additional information
  • Downloads
Description

15″ fanless Panel PC met Intel® N97 quad-core processor

  • True-flat touchscreen met industriële LCD-displaykwaliteit
  • Krachtige, fanless Intel® N97 quad-core processor
  • Slank en compact fanless ontwerp met behuizing van aluminiumlegering
  • Voorzijde met IP66-beschermingsgraad
  • Ondersteunt dual displays (1 x externe DisplayPort), iDoor en PCI- of PCIe-uitbreidingen
  • 1 x M.2 M-Key 2280 (SATA of NVMe PCIe x1) en 1 x 2,5″ SATA SSD slot
  • 2 x 2500BASE-T Ethernet met ondersteuning voor Time-Sensitive Networking (TSN) technologie
  • VESA 75-montage
  • TPM 2.0 hardwarebeveiliging

Certifications:

Additional information
Merk

Advantech

Montage

Panel montage

Processor

Quad core N97

Display

15 inch (4:3)

Downloads
  • Data sheet PPC-315S(W)_317S_318SW_319S_321SW-ADL
